WAI 2-1834-ND Starter

WAI 2-1834-ND Starter

Starter - Nippondenso OSGR
1.2kW/12 Volt, CCW, 13-Tooth Pinion
Post Buying Request Connecting Buyers Width China Suppliers
Big Picture

Similar Products

943253242010

MAGNETI MARELLI 943253242010 Starter

S512341

BTS Turbo S512341 Starter

944280162800

MAGNETI MARELLI 944280162800 Starter

A 10 460

ATL Autotechnik A 10 460 Starter

8080343

FRIESEN 8080343 Starter

10465411

DELCO REMY 10465411 Starter

6035628.1

SANDO 6035628.1 Starter

060104

DA SILVA 060104 Starter

4857

SPIDAN 4857 Starter

10478846

DELCO REMY 10478846 Starter

455009

VALEO 455009 Starter

25-4296

ELSTOCK 25-4296 Starter
     配件名称:WAI编号:零件所在位置:
        Armature, Str61-8214
                                Bracket, Soln
                                Nut 84-2203
                                Retainer, Soln66-82765
                                Rivet84-3921
                                Screw 84-1238
                                Sleeve, Soln
                        Bearing, Ball6-104-4
                        Bearing, Ball6-904-4W
                        Bracket Kit, Soln76-82251
                        Bushing, Str62-82801CLUTCH
                        Coil, Soln66-82459
                        Contact, Movable, Soln66-82651
                        Contact, Stationary, Sol66-82761BATTERY
                        Contact, Stationary, Sol66-82756MOTOR
                        Insulator, Soln INSIDE
                        Insulator, Str72-82415EXTERNAL
                        Insulator, Str72-82400EXTERNAL
                        Insulator, Str72-82409INTERNAL
                        Nut85-2402MOTOR TERMINAL
                        Nut85-2400BATTERY TERMINAL
                        O-Ring 71-82515BATTERY TERMINAL
                        O-Ring71-82512BATTERY TERMINAL
                        O-Ring71-82512MOTOR TERMINAL
                        Plate, Stop, Soln 66-82774
                        Repair Kit, Soln79-82102
                        Roller, Str54-82503
                        Spacer, Str
                        Spring, Clutch, Str Driv54-82602
                        Terminal Post, Soln66-82355BATTERY
                        Terminal Post, Soln66-82350MOTOR
                        Washer, Spring
                Bearing, Ball ARMATURE, REAR
                Bearing, Ball6-102-4ARMATURE, FRONT
                Brush, Str68-8215FIELD
                Brush, Str68-8214FIELD
                Clutch, Str Drive54-82408-1
                Coil, Soln
                Collar, Stop, Str76-82807
                Contact & Plunger Assy66-82608
                Contact Set, Stationary BATTERY
                Contact Set, Stationary MOTOR
                Cover, Soln
                Gasket, Soln66-82404COVER
                Grommet, Str
                Insulator, Soln
                Insulator, Str FIELD COIL
                Pinion, Str Drive54-82216
                Retainer, Str
                Retaining Ring, Str76-82806
                Shaft, Drive
                Spring, Brush, Str 69-82702
                Spring, Str Drive
                Terminal, Soln76-82571SWITCH
                Terminal, Str
        Ball, Steel, Str76-82802
        Boot, Str71-82301FIELD COIL
        Brush Holder Assy, Str69-8215
        Drive, Str
        Field Case Assy, Str
        Frame, CE, Str
        Gear, Str
        Housing, DE, Str
        Nut TERMINAL, BATTERY, SOLENOID
        Nut TERMINAL, GROUND
        O-Ring71-82510FIELD CASE
        Retainer, Str76-82810ROLLER, PINION
        Roller, Str76-82805
        Screw FRAME, CE
        Screw HOUSING, DE
        Spring, Plunger, Str66-82552
        Switch, Solenoid
        Thru Bolt85-1369
        Tube, Drain, Str71-82312FRAME, CE
