WAI 1-1993-12FD Alternator
Alternator - Ford 4G Series IR/IF
130 Amp/12 Volt, CW, 6-Groove/75mm OD Pulley | 配件名称: | WAI编号: | 零件所在位置: |
| Bearing, Ball | 6-303-4 | FRAME, DE |
| Shaft, Rotor | | |
| Bobbin, Rotor | 28-2306 | |
| Diode, Pos | 32-1040920 | |
| Diode, Pos | 32-1040900 | |
| Heat Sink, Pos | 31-2204 | |
| Magnet Wire | | |
| Pole Piece, Rotor | | |
| Repair Ring, Slip Ring | 28-2858 | |
| Shaft, Rotor | | |
| Terminal | | |
| Coil, Rotor | | |
| Collar, Stop, Alt | | |
| Dampener, Rotor | | |
| Diode, Neg | 32-1040921 | |
| Frame, SRE | 22-213 | |
| Pole Piece, Rotor | | FRONT |
| Pole Piece, Rotor | | REAR |
| Rectifier, Pos | FR300P-1-B80 | |
| Rivet | 84-3918 | |
| Shaft, Rotor | | |
| Slip Ring, Rotor | 28-2857 | |
| Brush, Alt | 38-215 | |
| Fan, Rotor | 28-2412 | FRONT POLE PIECE |
| Fan, Rotor | 28-2411 | REAR POLE PIECE |
| Fixture, Tester | VRC101-33 | |
| Harness, Repair, Alt | 46-2802 | |
| Rectifier | FR300-1 | |
| Rotor | | |
| Sleeve, Packaging | | |
| Spring, Brush, Alt | 39-2701 | |
| Stator | 27-212-1 | |
| Test Lead, Alt | WAA784 | |
| Bearing, Ball | 6-203-84W | FRAME, RECTIFIER |
| Cover, Alt | 46-2450 | FRAME, RECTIFIER |
| Frame, DE, Alt | | |
| Nut | 85-2600 | PULLEY |
| Pulley | 24-2274 | |
| Regulator & Brush Holder | F796 | |
| Retainer, Bearing, Alt | 46-2504 | FRAME, DE |
| Rotor | 28-210-2 | |
| Screw | 85-1217 | REGULATOR |
| Screw | 85-1346 | RETAINER, BEARING |
| Stator & Rectifier Assy | | |
| Thru Bolt | 85-1345 | |
