WAI 20-1159-31 Alternator

Alternator - Delco CS144 Series
140 Amp/12 Volt, CW, 6-Groove Pulley, 07:30 Plug Clock

Post Buying Request Connecting Buyers Width China Suppliers

Similar Products

943356229010: MAGNETI MARELLI 943356229010 Alternator

59212985: ARTEC 59212985 Alternator

111712: HC-Cargo 111712 Alternator

2015284.1: SANDO 2015284.1 Alternator

0 120 489 761: BOSCH 0 120 489 761 Alternator

9213878: PowerMax 9213878 Alternator

930625: EDR 930625 Alternator

1100293: DELCO REMY 1100293 Alternator

079821: VALEO 079821 Alternator

12090076: EUROTEC 12090076 Alternator

AEA5180: AUTOELECTRO AEA5180 Alternator

0 986 JR1 578: BOSCH 0 986 JR1 578 Alternator

配件名称:	WAI编号:	零件所在位置:
Bearing, Needle Roller	8-122-3	FRAME, SRE
Sleeve, Packaging	89-916
Bearing, Ball	6-303-4	FRAME, DE
Brush Holder, Alt	39-1207
Brush, Alt	38-115
Brush, Alt	38-117
Compound, Sleeve Retain	89-214
Frame, DE, Alt	21-156
Frame, SRE, Blank
Heat Sink, Neg
Heat Sink, Pos
Pin, Alt	39-1501
Race, Bearing	8-121-3
Retainer, Bearing, Alt	46-1509	FRAME, DE
Screw	84-1212
Slip Ring, Rotor	28-1855
Spacer, Alt	46-2602
Spring, Brush, Alt	39-1701
Terminal Block, Alt
Bearing, Needle Roller	8-122-3	FRAME, SRE
Brush Holder Assy, Alt	39-108-3
Capacitor	46-1104
Connector, Alt	46-1310	RECTIFIER TO REGULATOR
Cover, Alt	46-1458	BRUSH
Fan, Alt	25-103
Frame, DE, Alt	21-156
Frame, SRE	22-154
Insulator, Alt	42-1106	FRAME, SRE
Insulator, Alt	42-1311
Nut	84-2700	PULLEY
Nut	85-2301	TERMINAL, BATTERY
Nut	84-2200	RECTIFIER
Pulley	24-1281
Rectifier	DR5179
Regulator, Alt	D712
Rotor	28-133
Screw	84-1212	RECTIFIER
Screw	84-1205	CAPACITOR & RECTIFIER
Screw	84-1225	BRUSH HOLDER
Screw	84-1226	RECTIFIER
Screw	84-1226	REGULATOR
Spacer, Alt	46-1619-1	ROTOR
Spacer, Alt	46-1617-1	FAN
Stator	27-133
Terminal, Battery, Alt	46-1178
Thru Bolt	84-1304
Washer, Lock	84-4606	PULLEY
